WATERBATH FOR SPECIFIC GRAVITY TEST OF CEMENT

Compliance Standards:

IS : 4031 (Part-11), ASTM C188, EN-196

Applications

The water bath in general will fulfill the requirements of IS:4031 (Part 11) Method of Physical tests for hydraulic cement (Determination of Density),

Technical Details

1. Microprocessor based digital temperature controller system.
2. Capable of maintaining temperature within + 0.1˚C accuracy
3. Drainage System
4. Stand for each Le-Chatlier Flask cap. 250ml (8 Nos.)
5. It will be attached with cooling & heating arrangement system.
6. It will be fully covered.
7. Water bath body will be insulated.
8. Control panel will be at side of the bath.
9. Water circulation/stirrer will be provided to maintain uniform temperature of water.
10. Transparent (toughened glass) sheet will be provided in front and back position.
11. Supplied without Le-Chatelier Flasks.

The following Items are required to perform the test and available at extra cost

1. Electronic Weighing Balance with sensitivity of 0.0001 gm
2. Kerosene
3. Le-Chatlier Flask
4. Micro Funnel - 20mm dia
