DRY BATH - FOR 15 GLASS TUBE OF 24 MM DIA X 15 CM LENGTH
Model Number : EIE-DB152415
DRY BATH - FOR 15 SAMPLES OF 24 MM DIA X 15 CM LENGTH
Construction Details:
- Outer cabinet is made of mild steel duly powder coated.
- Double wall construction with insulation for minimum heat losses increases the efficiency of the system.
- Aluminum Block with holes (Dimension 26 mm Diameter x 150 mm Depth) is used to hold 15 Nos tubes.
- Aluminum Block is heated to maintain temperature up to 220° C
- Solid state Digital Temperature Controller, appropriate heater & insulation selection assure uniformity in all the samples.
- Selectable timer up to 120 min/h alarm is provided to set the digestion period.
- Supplied without Glassware
| Temperature Range | Above ambient to 220° C or higher |
|---|---|
| Temperature Resolution | 0.1° C |
| Display | Digital 12mm Red LED |
| Control | Digital Electronic Temperature Controller |
| Heater Rating | 750 Watts |
| Sensor | PT-100 |
| Timer | Selectable 15, 30, 45, 60, 90 or 120 minutes with alarm |
| Hole Size | 26 mm Diameter x 150 mm Depth |
| Glass Tube | 24 mm diameter, 150 mm length |
| Overall size | 27 x 15 x 11" |
| Net weight w/o packing | 31 kilograms |
