DISSOLVED OXYGEN CONTROLLER
Model Number : A10DO-AA2/GT-101C.5
Specifications
- 4-20 mA Output
- 3-Relay
- 100-240 volts AC.
- IP-65 compliance
| Oxygen (02) Measurement | |
|---|---|
| Range | 0-20 ppm |
| Accuracy | ±1 % of full scale |
| Resolution | 0.1 ppm |
| Temperature Measurement | |
| Range | 0 to 50° C |
| Accuracy | ±0.5° C |
| Resolution | 0.10 C |
| Temperature compensation | 0 to 50° C |
| Salinity Compensation | 0-50 ppt |
| Pressure | (Barometric correction) - 500 to 1499 mm Hg |
| Display | 1 line, 8 characters LCD |
| Power | 9V battery or mains adaptor 9-12V |
| Dimension | 80(W) X 42(D) X 175(H) mm |
| Weight | 500gm (Approx) |
| Sensor DO Probe | Gold and Silver with FEP Gas permissible membrane |
| Temperature Probe | PT 100 |
| Accessories | Combined D.O. and Temp. Probe along with protective cover |
| 9V Battery | |
| FEP Teflon Membrane |
