KJELDAHL DIGESTION AND DISTILLATION COMBINED-WITHOUT GLASS PARTS-3 TEST POSITION
Model Number : EIE-216EPWO3
Electrically heated, comprising of one single mild steel tubular stand provided with two shelves one above the other. A specially designed glass fume duct with B 24) Cone openings (suitable for flasks having 24/29 socket) having such provision so that no leakage of fumes takes place. One heater box having individual energy regulators for 500 watts The whole unit is operated on 220 volts AC mains.
Brief Construction Details
- Electrically heated unit
- Aesthetic exterior appearance
- Powder coating in attractive shades.
- Comprises of one single mild steel tubular stand with two shelves - one above the other.
- A specially designed glass fume duct with B-24 Cone openings (suitable for flasks having 24/29 socket) having such provision so that no leakage of fumes takes place will be a part of standard supply.
- One heater box having individual energy regulators for 500 watts heaters are supplied in digestion part at the lower side.
- One heater box of having individual energy regulators for 500 watts heaters is supplied in distillation part at the upper side.
- Distillation part is also provided with brass condenser rack with water circulation systems
- The whole unit is operated on 220 volts AC mains.
Following glass parts and accessories will be at extra cost. (Essential accessories)
1) Distillation part
- Kjeldahl distillation flask - 500 ml - 03 Nos (300 or 800ml also available)
- Two Neck adopters - 03 Nos
- Dropping Funnel - 03 Nos
- Splash Head Vertical - 03 Nos
- Liebig Condenser - 03 Nos
- Receiving Adopters - 03 Nos
- Conical Receiving flask - 500 ml - 03 Nos
- Clamp supports for Distillation unit - 02 Nos
2) Digestion part
- Kjeldahl digestion flask - 500 ml - 03 Nos (300 or 800ml also available)
- Glass Fume Duct - 01 Nos
- Clamp supports for Digestion unit - 02 Nos
Rubber Tubing, Condenser clamps, Bosshead etc. also to be procured at extra cost
