LOW TEMPERATURE WATERBATH - +5°C TO 50°C - 20 LITERS CAPACITY-COMPLETE SS 304

LOW TEMPERATURE WATERBATH - +5°C TO 50°C - 20 LITERS CAPACITY-COMPLETE SS 304

Model Number : EIE-413DP20

The bath is double walled, inner chamber consisting of thick polished stainless steel with cooling coil duly soldered on the outside of the same to ensure perfect cooling effect to achieve low temp. up to +5°C. The outer wall is of thick stainless steel sheet duly pre-treated and powder coated for longer life. The hollow space between the inner chamber and outer wall is filled with high grade insulation of thickness 75 mm to prevent loss of temperature.The refrigeration system consisting of Hermetically sealed compressor for minimum noise level and smooth operation, Coupled with other quality components, it ensures a high degree of reliability over a long period. Heating system comprises of immersion type heating element for attaining above ambient temperature. The unit is provided with a high performance circulation stirrer to circulate the inside fluid to ensure a constant and uniform temperature throughout. Temperature range 5°C to 50°C with PID digital temperature controller cum indicator. Chamber size. : 300 x 250 x 200 mm.

Salient Features:

  • Double walled
  • Highly efficient model
  • Aesthetic outer appearance
  • Easy operation and hassle free maintenance
  • Automatically maintains the set temperature
  • Complete with re-circulating unit for temperature uniformity
  • Incorporates CFC Free refrigeration compressor
  • Fitted with immersion heaters and compressor in order to maintain the set temperature
  • Multi purpose unit useable for many other laboratory applications


Details

  • Inner chamber consists of thick polished stainless steel with cooling coil duly soldered on the outside to ensure perfect cooling effect to achieve low temp. up to +5°C.
  • The outer wall is of thick stainless steel sheet material for longer life.
  • The hollow space between the inner chamber and outer wall is filled with high grade insulation of thickness 75 mm to prevent loss of temperature.
  • The refrigeration system consists of Hermetically sealed compressor for minimum noise level and smooth operation, Coupled with other quality components, it ensures a high degree of reliability over a long period.
  • Heating system comprises of immersion type heating element for attaining above ambient temperature.
  • The unit is provided with a high performance circulation stirrer to circulate the inside fluid to ensure a constant and uniform temperature throughout.
  • Temperature range 5°C to 50°C with PID digital temperature controller cum indicator.
