BULK DENSITY CYLINDRICAL METAL MEASURE
Used for determining the unit weight and voids in aggregates as per standard test methods. The apparatus is made from thick gauge mild steel, ensuring rigidity and shape retention. Features a water-tight construction, smooth interior finish, and precision machining for accurate measurements. Fitted with handles for easy handling.
AUTOMATIC CENTRIFUGAL EXTRACTOR -
The automatic Bitumen Extractor is used for the separation and extraction of bitumen by use of perchloroethylene or trichloroethylene solvents and sieving, for the separation of filler by centrifuge action and for the recovery of solvent material. The complete cycle is carried out automatically. As per ASTM D2172 and EN 12697-1
POKER CHIP TESTING MACHINE-5 KN- FOR ASPHALT
The test method was developed by Texas department of Transportation.
AUTOMATIC ROLLING THIN FILM OVEN - PROGRAMMABLE
The Automatic Rolling Thin Film Oven is a precision laboratory device designed to evaluate the properties of bitumen and asphalt materials. It conforms to key standards including ASTM D2872, ASTM D6521, AASHTO T240, EN 12697-22, and ISO 4624. This oven offers a temperature range of 50-180°C with a control accuracy of ±1°C. It features programmable speed settings (5-60 rpm) and accommodates sample sizes ranging from 2 to 200 grams. Key safety features include over-temperature protection, automatic shut-off, and integrated control systems for temperature, speed, and timing. With Digital Flow meter and air flow regulator
ASPHALT CONTENT OVEN-(ASPHALT IGNITION OVEN)-(ASTM D6307)
Compliance Standards : ASTM D6307-98 and AASHTO T30. The Asphalt Content/Binder Furnace with internal automatic balance is an environmentally-friendly and cost-effective method for the accurate determination of asphalt content. Ignition method reduces testing time compared to solvent testing methods and automatic operation frees technicians for other tasks. Accurate internal balance monitors weights automatically throughout ignition. Easy operation- simply enter sample weight, calibration factor, load the sample, and push start, when unit beeps at test end, push stop, and sign receipt. Model approved and certified by IIT Gandhinagar
VOLATILE MATTER CONTENT APPARATUS-FOR TAR AND BITUMEN MATERIAL-BIS 1220
To determine the volatile matter content of tar and bituminous materials by measuring the loss of weight upon heating.
ROLLING THIN FILM OVEN
The Rolling Thin Film Oven (RTFO) is designed to evaluate the short-term aging resistance of bituminous binders. This test simulates the hardening process that occurs during the mixing of binder with aggregates in a plant and the subsequent finishing and rolling of bituminous layers. The RTFO assesses how the binder's properties change under heat and air exposure, providing critical data on its durability and performance. The RTFO test involves subjecting the binder to controlled heat and airflow to simulate aging conditions, preparing samples for further evaluation of their performance characteristics. Complies with: ASTM D2872 / AASHTO T240 / CNR N.54 / EN 12607-1 / IS 15799-2008.
FULLY AUTOMATIC STANDARD PENETROMETER - (ASTM D5, ASTM D217)
Supplied with standard accessories relevant to perform on a wide variety of materials such as grease, petroleum, Wax, Polish, foodstuff, rubber asphalts and Pharmaceutical creams with the appropriate penetration tools and Cups, which are available at extra cost on demand.
FULLY AUTOMATIC RING AND BALL APPARATUS - (ASTM D36)
The softening point test determines the temperature at which bitumen or other bituminous materials soften under specified conditions. The test is essential for evaluating the consistency and temperature susceptibility of bituminous binders used in road construction and other applications. Can also be supplied for the Thermoplastic Adhesive, Resin, Plastic, Paraffin wax, rubber, grease and various other material as per their respective test standards.
REFRIGERATED WAX CONTENT APPARATUS - IS 10512-2003
The Wax Content Testing Apparatus, as per IS 10512:2003, enables accurate determination of paraffin wax content in bitumen and bituminous binders through controlled distillation. Designed for precise, standardized analysis, it is ideal for laboratories handling bitumen quality assessment. As per IS 10512:2003,ASTM D721, IP 47
ABSOLUTE AND KINEMATIC VISCOSITY BATH
As per IS: 1206 (Part II and III).Supplied complete with Viscosity bath with built in Digital stop watch, Vacuum Pump - capable to maintain vacuum of 300 mm/Hg, Indian Make Vacuum Manning Viscometer No.12 and 13, Reverse flow Viscometer No.6, Silicon oil, silicon tubes and calibration certificate for Viscosity bath, certificate of constant for Viscometers. Complete with instruction manual. Canon USA Make Glass U Tube Viscometer, Mercury Manometer, Digital Vacuum Indicator cum controller etc. are available.
APPARATUS FOR DISTILLATION OF CUT BACK ASPHALT
Complying with ASTM D402, IP 27, and IS 1213 standards. Supplied complete with ASTM 8C glass thermometer, 500 ml distillation flask, 100 ml crow receiver, and all required accessories. Features an electrically heated system.Equipped with both an Energy Regulator and a Digital Temperature Controller for precise operation.
LOSS ON HEATING OVEN-(IS:1212 / ASTM D6)
Apparatus for loss on heating test of Tar & Bitumen As Per IP 45, IS 1212, ASTM D6-90, AASHTO T-47, EN 13303.
HARDNESS TESTER FOR BITUMEN MASTIC ASPHALT - IS 1195-1978:
Supplied with Digital waterbath, a Glass Thermometer and a Digital stop watch. As per IS 11195-2002 (R.A.2017) BS 6925-1988.
PARTICLE CHARGE TESTER - (ASTM D244) - WITH ACCESSORIES
EN 1430, ASTM D244
INDIRECT TENSILE STRENGTH OF MARSHAL TEST SPECIMEN
Tensile Splitting Device (Lottman Breaking Head) – ASTM D6931 Designed for 4" (100 mm) and 6" (150 mm) Marshall compacted bituminous specimens, complete with loading strips. Supplied with the breaking head assembly, guide rods, and loading strips.(Marshall machine, water bath, and oven are not included.)
CAMBER BOARD - FOR ROAD CONSTRUCTION
A camber board is a simple tool used in road construction to ensure the correct camber (slope) of the road surface during its construction. The camber is the slight transverse slope provided to the surface of the road to facilitate drainage. The camber board is typically a metal frame, shaped to match the required camber profile (convex or straight slope) and used by road workers to level the road surface during the laying of materials like asphalt or concrete.
DENSITY CUP-STAINLESS STEEL-83.2 ML-ASTM D6937-SPECIFIC GRAVITY OF BITUMEN EMULSION
Used for the determination of the density of emulsified asphalt (bitumen emulsion) at 25°C (77°F). The density of the bitumen emulsion is used to calculate its specific gravity and is important in determining its application in construction, particularly in ensuring that the correct amount of material is used in road construction or other applications.Compliance standards - ASTM D6937.
DUCTILITY TESTING MACHINE
Bitumen Ductility Testing Machine as per (IS:1208) Used to determine the ductility of bitumen by measuring its elongation before breaking under controlled conditions. Helps evaluate adhesion and flexibility for pavement applications.Semi-automatic, non-digital model with thermostatic temperature control. Supplied with 3 Nos. ductility moulds. Available in refrigerated and non rerigerated models. Elastic recovery moulds available separately
LENGTH GAUGE
Used to determine the Elongation Index of the Aggregate. Aggregate particles are considered elongated when their length is more than 1.8 of the nominal size.It consists of a hard wooden base with vertically mounted metal studs as specified in the IS.
BENKLEMAN BEAM APPARATUS
The Benkelman Beam test is widely used to evaluate the deflection of flexible pavements under a standard wheel load, which helps assess the structural condition and design appropriate overlays. As per IRC: 81-1997, ASTM D4694, AASHTO T 256
