TRIAXIAL SHEAR TEST APPARATUS - FOR 38MM DIA SPECIMEN - FOR UU, CD AND CU.
As per (IS:2720 Part XI & XII ) for determining the shear strength parameters of saturated soils from triaxial compression shear tests conducted under consolidated undrained conditions with measurements of pore water pressures. The Triaxial Test System provides triaxial compression tests on cylindrical undisturbed and remolded soil samples. Unconsolidated undrained (UU), consolidated drained (CD) and consolidated undrained (CU) compression tests can be carried out using this apparatus. Supplied complete with Triaxial cell for 38mm dia specimen, Loading Frame 50 KN with 6 different speeds, Proving ring 2 KN with Calibration report, Dial Gauge 0.01 X 25mm travel, Analog readout to measure pore water pressure and Air/Water Constant Pressure system with air compressor.. To work on 220/230 Volts, single phase, AC power supply. Volume Change Gauge, De-airing apparatus, Accessories for soil sample preparation, extrusion, trimming and for measurement of size, weight, water content, etc. can be supplied at extra cost .
DIGITAL VACUUM REGULATOR FOR KINEMATIC VISCOSITY BATH-FOR 4 VISCOMETERS
For Precise Measurement and Control of Vacuum at 300 mm Hg Below Atmospheric Pressure: Ideal for method ASTM D2171
ELECTRONIC WEIGHING BALANCE-200 GM-0.001 GM (1 MG)-EXTERNAL CALIBRATION-MODEL SAB 203-
With RS-232 Standard, USB Interface
CHARACTERISTIC OPENING SIZE APPARATUS-WET SIEVE OPENING SIZE TESTER FOR GEOTEXTILE-EN ISO 12956
Compliance Standards : EN ISO 12956. To determine the characteristic opening size of a Single layer geotextile or geotextile related products, using the wet sieving principle.
DIRECT READING DIGITAL PENETROMETER - FOR BITUMEN
As per IS 1203, IS 1448. ASTM D5. In addition to regular features, this model is Fitted with Micrometer differential gearing system for fine movement of penetration needle. Complete with Automatic Digital Timer, Digital Penetration indicator, Penetration cup and transfer dish. Water bath to condition the sample is available at extra cost.
DIGITAL THICKNESS GAUGE - DEAD WEIGHT TYPE - 2 KPA, 20 KPA - 0.001 X 10 MM - INSIZE - ASTM D5199
A thickness gauge is used to determine the thickness of geosynthetics and similar materials under specified pressures and conditions. The standards ASTM D5199, IS 13162 (Part 3), and EN ISO 9863-1 outline the test methods and equipment specifications required for accurate measurement.
DIGITAL DEAD WEIGHT TYPE THICKNESS GAUGE - 2/20/200 KPA - 0.001 X 12MM
This is a Precision Instrument for measuring the Thickness of Paper ,Plastic Film, Laminates, Foil or Board. A Digital dial gauge is mounted on the base with a Dead Weight on top so as to develop a uniform, reproducible constant pressure on the anvil through the foot. Various other models to suit different application also available.
MOR TESTING MACHINE-1000 KGF-UP TO 60 X 60 CM TILES-SERVO CONTROLLED (BIS 13630 PART 6, ISO 10545-4)
IS: 13630 (Part - 6), ISO 10545 (Part-4)
APPARENT OPENING SIZE APPARATUS-ASTM D4751
Complying with ASTM D4751, BS 6906 (Part 2), IS 14294. The complete test set up essentially requires Ro-Tap Sieve Shaker, Fine sieves of 200mm diameter, Clamping arrangement, Spherical Glass beads and Electronic Balance. Here we supply only Rotap Sieve shaker. Fine Sieves, Clamping arrangement, Glass beads and Electronic Balance are essential accessories to conduct the test and are supplied at extra cost.
TEST SPECIMEN HOLDER - FOR SURFACE ABRASION MACHINE - FOR GLAZED TILES - BIS 13630-11, EN ISO 10545-7
Complies with IS 13630 (Part 11), EN ISO 10545 (Part 7). Supplied without steel balls of 1mm, 2mm, 3mm and 5mm diameter, which has to be procured at extra cost.
