FLOW TABLE (CEMENT) -HAND OPERATED - 25CM DIA - GUNMETAL TOP - IS 5512
Model Number : TM-79-GM
As per IS:5512. The flow table consists of a brass table top 250 ± 2.5 mm dia mounted on a rigid stand. The table top is reinforced with equally disposed ribs and allowed to drop through 12 mm by a ground and hardened cam, Complete with mould - 100 mm base dia, 70 mm top dia and 50 mm high.
FLOW TABLE VARIETY (FOR CEMENT)
- FOR BUILDING LIMES - HAND OPERATED - 30CM DIA - AS PER IS 6932
- HAND OPERATED - 25CM DIA - GUNMETAL TOP - IS 5512
- HAND OPERATED - 25CM DIA - STEEL TOP - IS 5512
- HAND OPERATED - GUNMETAL TOP - (ASTM C230)
- MOTORISED - (ASTM C230)
- MOTORISED - 25CM DIA - GUNMETAL TOP - IS 5512
- MOTORISED - 25CM DIA - M.S. TOP - IS 5512
- MOTORISED - 30CM DIA - AS PER EN 1015-3
As per IS:5512. The flow table consists of a brass table top 250 ± 2.5 mm dia mounted on a rigid stand. The table top is reinforced with equally disposed ribs and allowed to drop through 12 mm by a ground and hardened cam, Complete with mould - 100 mm base dia, 70 mm top dia and 50 mm high.
Product Description & Key Features :
- Flow table apparatus is engineered to precisely measure the consistency of mortars in accordance with IS 5512 standards. It provides reliable and reproducible test results for quality control and research applications
- Determines the consistency (flow) of mortars used in testing hydraulic cements and pozzolanic materials
- Features an integrally cast rigid iron frame for stability and a robust, machined brass (or gun metal) circular table top
- The table is designed to be raised and dropped vertically through a precise height of 12 mm by a ground and hardened cam, ensuring consistent operation
- Manual (Standard): Operated via a hand wheel mounted on the cam shaft
- Key wearing surfaces of the cam tip and vertical shaft are case-hardened mild steel for extended lifespan and reliability
Table Specifications :
- Diameter: 250 ± 2.5 mm
- Mass (Table & Shaft): 4.00 ± 0.05 kg
- Surface: Fine machined plane surface with scribed radial stiffening ribs and three inscribed annular circles
Included Accessory Apparatus :
- The complete apparatus includes essential accessories for immediate use.
- Conical Mould: Made of cast brass with a wall thickness of at least 5 mm. Dimensions are 100 mm internal diameter at the base, 70 mm internal diameter at the top, and 50 mm height.
| Overall Dimensions | 150 X 360 X 270 (L X W X D) mm |
|---|---|
| Weight (Approx.) | 10 Kg |
