BITUMEN EXTRACTOR-WITH FLAMEPROOF MOTOR - (ASTM D2172)
BITUMEN EXTRACTOR VARIETY
Complies with following International Standards
ASTM D 2172, AASHTO T 58, T 164
Application
This is used for a quantitative determination of bitumen in hot mix paving mixtures and pavement samples.
Construction Details
- Safe & Portable model of sufficient size for quick and accurate determination of bitumen.
- Corrosion-resistant model which can be used both in the field and the laboratory.
- Consists of a removable cast aluminum rotor bowl mounted on a vertical shaft.
- A filter paper disc is pressed in between the nut.
- The bowl assembly is enclosed in a housing mounted on a cast aluminum body.
- The gears operate in oil bath with splash lubrication.
- Special model with Flameproof Motor, DC-Motor drive and Electronic speed control and Digital RPM Indicator
Salient Features
- Flameproof Motor
- Electronic Speed Control
- Facilitates precise speed control
- Offers Vibration free smooth operation
- With a brake control for rapid deceleration
- Internal wiring as per CE Standards
- Safety label as per CE Norms
- Bowl Capacity : 1500 grams
- Variable speed : 50-3600 RPM
- Power Supply : 220 Volt, 50-60 Hz, Single Phase, AC Supply
- Removable Aluminum integral cup for adding solvent
- All parts of the body are seamlessly argon welded
- Essential parts of the instrument are hard chrome plated
- Digital RPM Indicator continuously display the RPM on screen
Essential Accessories At Extra Cost
- Filter paper - Box of 100 @ $ 12.00
- Electronic Balance (Capacity : 6000 gms, Accuracy : 0.1 gm) @ $ 190.00
- Electronic Balance (Capacity : 5000 gms, Accuracy : 0.01 gm) @ $ 850.00
- Benzene or Toluene to be procured locally.
- Animated Video CD with Commentary on the Working of the Instrument can be Provided at Extra Cost of Rs. 3000.00
- The Video CD Covering Demonstration of 15 Different Instrument on Bitumen & Aggregate Testing can be Provided at Discounted rate of Rs. 30000.00
